Model
|
CS6510-48S6CQ-HI
|
|
Port
|
48*10G SFP+ ve 6*40G QSFP
|
|
Yönetim Portu
|
Konsol port RJ4510/100/1000Mbps RJ45 Ethernet Yönetim Portu USB2.0 Yönetim portu
|
|
Anahtarlama Kapasitesi
|
1440Gbps
|
|
İletim Hızı
|
1071Mpps
|
|
MAC Adres Tablosu
|
96K(standard)/32K(routee)/288K(bridgee), UFT configuration
|
|
ARP Tablosu
|
208k(standard)/16k(routee)/16k(bridgee), UFT configuration
|
|
Yönlendirme Tablosu
|
8k(standard)/128k(routee)/8k(bridgee), UFT configuration
|
|
Fiziksel
|
||
Ölçüler
|
433.8mm*44mm*550mm
|
|
Bağıl Nem
|
%10~%90, yoğuşmasız
|
|
Sıcaklık
|
Çalışma 0°C~50°C, depolama -40°C~75°C
|
|
Güç Girişi
|
AC: 100~240V,50~60 Hz
|
|
Güç Kaynağı
|
1+1 Modüler yedek
|
|
Ana Özellikler
|
||
L1, L2 Özellikleri
|
|
|
12k Jumbo FramePort Loopback DetectLLDP ve LLDP-MEDUDLD802.3ad LACP, max 128 group trunks with max 8 ports for each trunkLACP Load Balance
|
||
N:1
RSPAN
ERSPAN
|
||
IEEEE802.1d(STP)
IEEEE802.1w(RSTP)
IEEEE802.1s(MSTP)
Root Guard
BPDU Guard
BPDU Tunnel
|
||
802.1Q, 4096 VLAN
MAC VLAN, VOICE VLAN, PVLAN, Protocol VLAN, Multicast VLAN
QinQ, Selective QinQ, Flexible QinQ
GVRP
N:1 VLAN Translation
Broadcast / Multicast / Unicast Storm Control
|
||
IGMP v1/v2/v3 Snooping and L2 QueryND SnoopingMLDv1/v2 Snooping
|
||
Port Güvenliği
|
||
Flow control: HOL, IEEE802.3x Bant Genişliği Kontrolü
|
||
L3 Özellikleri
|
Static Routing, RIPv1/v2, OSPFv2, BGP4OSPFv3, BGP4+OSPF Multiple ProcessLPM RoutingPolicy-based Routing (PBR) for IPv4 and IPv6VRRPURPF,ECMP
BFD
|
|
IGMP v1/v2/v3, IGMP Proxy,DVMRP, PIM-DM, PIM-SM, PIM-SSM, any cast RP, MSDPStatic Multicast RouteMulticast Receive ControlIllegal Multicast Source Detection
|
||
ARP Guard, Local ARP Proxy, Proxy ARP, ARP Binding, Gratuitous ARP, ARP LimitAnti ARP Cheat, Anti ARP Scan
|
||
DNS Client
|
||
GRE Tunnel
|
||
IPv6
|
6to4 Tunnel, Configured Tunnel, ISATAP Tunnel, GRE TunnelICMPv6, ND, DNSv6IPv6 LPM Routing, IPv6 Policy-Based Routing (PBR)IPv6 VRRPv3, IPv6 URPF, IPv6 RARIPng, OSPFv3, BGP4+MLD Snooping, IPv6 multicast VLANMLDv1/v2, PIM-SM/DM for IPv6, IPv6 Anycast RP, IPv6 ACL, IPv6 QOS
|
|
MPLS
|
MPLS, VRF, LDP
|
|
MPLS L3 VPN, MPLS L2 VPN(VPLS), VPWS
|
||
QoS
|
8 QueuesSWRR, SP, WRR, DWRR, SDWRR, WREDTraffic Classification Based on 802.1p CoS, ToS, DiffServ DSCP, ACL, port numberTraffic ShapingPRI Mark/Remark
|
|
ACL
|
IP ACL, MAC ACL, IP-MAC ACLStandard and Expanded ACL Based on source/destination IP or MAC, IP protocol, TCP/UDP port, DSCP, ToS, IP Precedence), VLAN, Tag/Untag, CoSREDIRECT and accounting-based ACLRules can be configured to port, VLANTime ranged ACL
|
|
Güvenlik
|
802.1x AAAPort, MAC based authenticationAccounting based on time length and trafficGuest VLAN and Auto VLAN
|
|
RADIUS for IPv4 and IPv6
|
||
TACACS+ for IPv4 and IPv6
|
||
MAB
|
||
DHCPv4/v6
|
DHCP Server/Client for IPv4/IPv6DHCP Relay/Option 82DHCP Snooping/Option 82
|
|
Trafik Monitörü
|
sFlow Trafik Analizi
|
|
Güvenlik Ağ Yönetimi
|
CLI, WEB, Telnet, SNMPv1/v2c/v3 through IPv4 and IPv6Syslog and external Syslog serverHTTP SSLSNMP MIB, SNMP TRAPFTP/TFTPSNTP/NTPRMOM 1,2,3,9Authentication by radius
SSH v1/v2
Dual firmware images/ Configuration files
802.3ah OAM, 802.1ag OAM
OpenFlow 1.0 (support open controller Opendaylight, Floodlight, Ryu, Pox, etc.)
|
|
Data Center Özellikleri
|
IEEE VEPA (Virtual Ethernet Port Aggregator) *
TRILL *
VXLAN *
VSF (Virtual Switch Framework)
|
