IS3600

Model	IS3600
Teknoloji
Standartlar	IEEE 802.3u for 100BaseT(X) and 100BaseFX IEEE 802.3ab for 1000BaseT(X) IEEE 802.3z for 1000BaseX IEEE 802.3x for Flow Control IEEE 802.1D-2004 for Spanning Tree Protocol IEEE 802.1w for Rapid STP IEEE 802.1s for Multiple Spanning Tree Protocol IEEE 802.1Q for VLAN Tagging IEEE 802.1p for Class of Service IEEE 802.1X for Authentication IEEE 802.3ad for Port Trunk with LACP
Performans
İletim Hızı	10Mbps:14880pps 100Mbps:148800pps 1000Mbps:1488000pps
Anahtarlama Kapasitesi	IS5600E-28M: 12.8Gbps IS5600G-28M: 56Gbps
IGMP Grupları	4K
MAC Tablosu	IS3600E-28M: 8K IS3600G-28M: 16K
VLAN number available	4K
Öncelik Kuyruğu	8
Buffer Size	32M
ACL Rules	1K
Jumbo Frame	2048 bytes
Portlar
Sabit Portlar	IS3600E-28M	4 * 10/100/1000 Combo Ports 3 Extended Slots
	IS3600E-28M	4 * 10/100/1000 Combo Ports 3 Extended Slots
Extended Module	IS3600E-28M	8-port 10/100TX module with RJ-45 connector
		8-port 100Mbps SFP module
		4-port 100Mbps multi/single mode fiber module with SC/ST connector
	IS3600G-28M	8-port 10/100/1000T module with RJ-45 connector
		8-port Gigabit SFP module
		4-port 1000Mbps multi/single mode fiber module with SC/ST connecto
Port Mirroring	Port monitor 1:1, n:1
Port Trunk	IEEE802.3ad, LACP
Yönetim Portu	Konsol
LED Işıkları	POWER, Management Status, Link/Active and Transceiver
Bant Genişliği Kontrolü	64kbps
Storm Control	Broadcast / Multicast / Unicast Storm Control
Port Koruma	MAC binding , MAC address filter, MAC limit
VCT&DDM	VCT
Port Loop Detection	Var
Port İzolasyonu	Var
Ana Özellikler
İletim Modu	Sakla ve İlet
VLAN	Port-based VLAN IEEE 802.1Q, up to 4094 VLANs MAC tabanlı VLAN Protokol tabanlı VLAN Private VLAN GVRP Normal QinQ, selective QinQ
DHCP	IPv4/IPv6 DHCP Client,IPv4/IPv6 DHCP Relay Option 82,Option 37/38 IPv4/IPv6 DHCP Snooping, IPv4/IPv6 DHCP Server
Reliability	Spanning Tree	802.1D STP, 802.1W RSTP, 802.1S MSTP Root Guard, BPDU Guard, BPDU Forwarding
	LACP	LACP support Load balance
	L2 Ring Protection	Ring protection protocol (ERPS) Loopback Detection
Güvenlik	IP ACL, MAC ACL, MAC-IP ACL, User-Defined ACL Zaman Ayarlı ACL Port Security, MAC Limit based on VLAN and Port Anti-ARP-Spoofing , Anti-ARP-Scan, ARP Binding ND Snooping DAI IEEE 802.1x, MAB (MAC tabanlı kimlik doğrulama) Authentication, Authorization, Accounting Radius, TACACS+
Multicast	IGMP v1/v2/v3 snooping, IGMP Fast leave MVR IGMP packet filtering Multicast control MLD v1/v2 snooping
QoS	8 Queues Bandwidth Control Akış Yönlendirme Classification based on ACL, VLAN ID, COS, TOS, DSCP, IPv6 Flow Label Policing Based on Port and VLAN Single Rate Dual Colors Remark COS/802.1p, IP Precedence, DSCP, TOS SP, WRR, SP+WRR for scheduling
Bakım ve Yönetim	TFTP CLI, Telnet, Console, SSH (IPv4/IPv6) Web/SSL (IPv4/IPv6) SNMPv1/v2c/v3 Public & Private MIB interface RMON 1,2,3,9 Ping, Trace Route Radius Authentication Syslog (IPv4/IPv6) SNTP/NTP (IPv4/IPv6) Dual IMG, Multiple Configuration Files Port Mirror, CPU Mirror OAM 802.3ah VCT, DDM ULDP(like Cisco UDLD) LLDP/LLDP MED
Yeşil Enerji	Fansız Yapı
Donanım Özellikleri
Ölçüler	440mm x 300mm x 44mm (W×D×H)
Ağırlık	<4kg
Kurulum	Industry standard rack or arbitrary plane installation
Diğer	Fansız Yapı, IP40 koruma sınıfı
Elektriksel Performans
Güç Girişi	85~265V AC/DC
Güç Tüketimi	IS3600E-28M: <30Watts IS3600G-28M: <60Watts
Çalışma Ortamı
Çalışma Sıcaklığı	-40 to 80
Saklama Sıcaklığı	-45 to 80
Bağıl Nem	0% ~ 95%, Non-condensing
Yedeklilik
Ağ Yedekliliği	Support Ring Protection, <50ms Support single, dual and tangent ring Support STP/RSTP
Port Yedekliliği	Port Trunk Ring protection protocol(ERPS)
Standart ve Sertifikalar
ISO	ISO9001:2008
EMI	FCC Part 15 (Class A), EN55022 (CISPR22 Class A), EN55024 (Class A), CE, EN50121-3-2, EN50121-4 IEC61850
EMC	EN61000-4-2, EN61000-4-3, EN61000-4-4 EN61000-4-5, EN61000-4-6, EN61000-4-8, EN61000-4-12
Güvenlik	EN60950, UL508/cUL508, UL1604/cUL1604
